36 XR Series Installation and Technical Instructions
Configuration & Options
Switch 6: Start-up Auto-Learn
On power up, the XR automatically enters Auto-Learn mode, analyzing the
serial communications and string type. In certain situations, it may be
necessary to disable this feature. Once disabled, the LEARN button on the
controller board must be pressed before the XR will go into Auto-Learn
mode.
Switch 7: Reserved for Future Use
Switches 8 & 9: Multi-Drop ID
If Multi-Drop is not being used, it is
very important that Switches 8 & 9
be set in the OFF position.
Up to four (4) XR displays can share a serial or radio connection. Messages
are sent to individual displays using control codes and these Multi-Drop IDs.
For Multi-Drop instructions, see Multi-Drop addressing on page 46.
START-UP AUTO-LEARN SWITCH 6
ENABLED (Default) OFF
DISABLED ON
MULTI-DROP I.D. SWITCH 8 SWITCH 9
0 (Default) OFF OFF
1ONOFF
2OFFON
3ONON
