40 XR Series Installation and Technical Instructions
Configuration & Options
Switches 4 & 5: Multi-Drop ID
WARNING:
If Multi-Drop is not being used, it is
very important that Switches 4 & 5
be set in the OFF position.
Up to four (4) XR displays can share a serial or radio connection. Messages
are sent to individual displays using control codes and these Multi-Drop IDs.
For Multi-Drop instructions, see Multi-Drop addressing on page 48.
Switches 6 & 7: Radio Channel Select
The 900 MHz Radio Module (optional) has 4 frequency channels. If there are
multiple scale/remote display installations at a given site, each installation
must have its own radio channel selected.
If the wireless connection experiences interference problems from another
radio site, switching radio channels will most likely correct the problem.
The XR 2000 remote display must be configured with the same radio
channel as the wireless transceiver connected to the indicator. See Wireless
Set-up for All XR Models on page 28.
Switches 8 & 9: Utility Program Select
Please see the XR 2000 Utility
Programs on page 47 for program
overviews.
The XR 2000 has built-in utility programs that run in conjunction with the
normal display functions.
MULTI-DROP I.D. SWITCH 4 SWITCH 5
0 (Default) OFF OFF
1ONOFF
2OFFON
3ONON
RADIO CHANNEL SWITCH 6 SWITCH 7
0 (Default) OFF OFF
1ONOFF
2OFFON
3ONON
PROGRAM SW 8 SW 9
1 – NORMAL Mode (No program) OFF OFF
2 – FREEZE Weight ON OFF
3 – Reserved for future use OFF ON
4 – COMMAND mode. ON ON
