Chapter 1: Introduction 1
Chapter 1: Introduction
Pro Tools
®
|HDI/O by Avid
®
is a multi-channel
digital audio interface designed for use with
Pro Tools
®
| HDX, Pro Tools
®
| HD Native, and
Pro Tools
®
| HD systems. HD I/O features 24-bit
analog-to-digital (A/D) and digital-to-analog
(D/A) converters, and supports sample rates of up
to 192 kHz.
HD I/O comes in three standard configurations:
• 8 x 8 x 8 (8 analog in, 8 analog out, and 8 dig-
ital in and out)
• 16 x 16 analog in and out
• 16 x 16 digital in and out
You can also add or remove analog (ADC and
DAC) and digital cards for custom configurations.
Pro Tools | HD I/O Features
HD I/O provides up to sixteen discrete channels of
audio input and output, each with a four-segment
LED meter. The total available analog and digital
I/O is dependent on the configuration of Analog
and Digital Expansion I/O cards installed in
HD I/O.
Analog I/O
• Up to 16 channels of 24-bit D/A and A/D con-
verters for superior analog input and output at
sample rates of 44.1 kHz, 48 kHz, 88.2 kHz,
96 kHz, 176.4 kHz, and 192 kHz with Analog In
and Analog Out HD I/O cards
• Soft Clip and Curv limiting circuits to protect
against clipping on analog input
Digital I/O
• Up to 16 channels of 24-bit digital I/O, using
AES/EBU, TDIF DB-25, or Optical at sample
rates of 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz,
176.4 kHz, and 192 kHz with a Digital HD I/O
card
• Real-time sample rate conversion on digital in-
puts with a Digital I/O card (up to sixteen chan-
nels of AES/EBU, Optical, or TDIF)
• Support for S/MUX Optical for sample rates of
88.2 kHz and higher
• Support for 2 channels of S/PDIF Optical
(enclosed) with sample rates of up to 96 kHz
• 2 channels of AES/EBU I/O (enclosed) with
support for sample rates up to 192 kHz
• 2 channels of 24-bit-capable S/PDIF I/O
(enclosed) with support for sample rates up to
192 kHz
