Avid Technology VENUE S6L Handbook

Configuration 3
Maximum Expanded IO Capacity:
Up to 192 Stage Inputs, up to 96 Stage Outputs
Requirements:
•2x AVB-192 Network Cards in E6L Engine
•3x Stage 64s, each with:
Up to 8x 8-ch Input cards
Up to 4x 8-ch Output cards
Connections
All connections are made between an “A” port and a “B” port.
Single System Expanded I/O
