Specifications: Power
S6L Control Surface
Power
Parameter Measurement Units Accuracy (±) Notes
RMS Input Voltage 220 VAC 0.05% + 0.25V
Frequency 50 Hz 0.1% ± 1 digit
RMS Input Current 1.317 A 0.1% + 0.15A
Peak Input Current 61.188 A 0.2% + 0.5A Internally limited by AC supply
Crest Factor 1.68 1.5%
VA (Reactive) Power 288.8 VA 0.15% + 9 VA
Real Power 261.6 W 0.15% + 9 W
Power Factor 0.91 0.03
Current THD 16.65 %A EN61000-3-2 Class A compliant
S6L-32D Power Measurements, 110V/60Hz
Parameter Measurement Units Accuracy (±) Notes
RMS Input Voltage 110 VAC 0.05% + 0.25V
Frequency 60 Hz 0.1% ± 1 digit
RMS Input Current 2.425 A 0.1% + 0.15A
Peak Input Current 61.188 A 0.2% + 0.5A Internally limited by AC supply
Crest Factor 1.64 1.5%
VA (Reactive) Power 267.8 VA 0.15% + 9 VA
Real Power 257.8 W 0.15% + 9 W
Power Factor 0.97 0.03
Current THD 20.65 %A EN61000-3-2 Class A compliant
S6L-32D Power Measurements, 220V/50Hz
