Installation
Package Contents
Note: The pendant wall mount and pendant NPT mount are sold separately.
Ensure the camera package contains the following:
l
Avigilon H5A IR PTZ Camera
l
T20 star key
l
T10 star key
l
3 x RJ-45 crimp-on plug
l
External power and I/O wiring harness
l
Sprayer mounting bracket and installation screws (only for models with wiper)
If you are installing the camera with the pendant wall mount, ensure the package includes the following:
l
Pendant wall mount (IRPTZ-MNT-WALL1)
l
Mounting template sticker
If you are installing the camera with the NPT mount, ensure the package includes the following:
l
NPT mount (IRPTZ-MNT-NPTA1)
l
Lock nut
l
Thread sealing tape
Retrofitting an H4 IR PTZ
The Avigilon H5A IR PTZ camera provides easy retrofitting with Avigilon H4 IR PTZ camera installations, with
a few exceptions. Keep the following points in mind if you are swapping a new H5A IR PTZ with an installed
H4 IR PTZ:
l
Re-use the original mounting location. The H5A IR PTZ is designed to install into the same wall arm or
NPT mounting location as the H4 IR PTZ.
l
H4 IR PTZ PoE requirements are different from the H5A IRPTZ, which requires an IEEE 802.3bt
compliant Class 8 (90W) PoE injector. The legacy PoE injectors used with the H4 IR PTZ are probably
not compliant with IEEE 802.3bt and a new PoE injector should be sourced for the H5A IR PTZ
installation. The recommended PoE injector is POE-INJ-BT-90W-NA.
Installation 6
