Note: If you need to remove the RJ45 connector from the camera to check a network issue,
gently pull the cable towards the locking tab to release the RJ45 plug before pulling upwards.
10. Check that the Connection Status LED indicator indicates the correct state. For more information, see
ConnectionStatusLEDIndicatoron page23.
Securing the PTZ Camera
1. Push the PTZ camera into the mount adapter.
Note: Be careful not to trap any cables between the camera housing and the mount adapter.
Figure 3: Pushing the camera into the wall mount adapter. Figure 4: Pushing the camera into the NPT adapter.
2. Note: Once the camera housing is aligned to the adapter, turn the camera until it locks into
place.
Securing the PTZ Camera 14
