Avigilon 8.0C-H6SL-DO1-IR - Pendant Wall Mount Bracket View

Pendant Wall Mount Bracket View 15
1.
1-1/2” NPS thread mount
Female NPS thread mount for pendant camera installations.
2.
Pendant wall mount screws
Screws for securing the pendant wall mount to the mounting bracket.
3.
NPT pipe entry hole
A 3/4” NPT threaded hole for NPT pipe conduits.
Pendant Wall Mount Bracket View
1.
Bracket mounting holes
Points for mounting the pendant wall mount bracket to a mounting surface.
2.
Mounting tabs
Tabs for placing the pendant wall mount onto the bracket.
3.
Mounting points
Points for securing the pendant wall mount to the mounting bracket.
