Zooming and Focusing the DomeCamera 43
Place the shield on the dome and tighten the screw to secure the Weather Shield on to the camera.
3. Remove the protective cover on the outside of the dome bubble.
Zooming and Focusing the DomeCamera
Ensure this procedure is performed after the dome cover is installed so you can accommodate for the focus shift
caused by the dome bubble.
NOTE
If an Environmental camera model is powered while the temperature is below -30°C (-22°F), the
zoom and focus may be disabled for the first 45 minutes while the camera warms up.
l
In the camera web browser interface, the Avigilon Unity Video or Avigilon Control Center software, use the
camera’s Image and Display settings to zoom and focus the camera.
a. Use the zoom buttons to zoom the camera in or out.
b. Click Auto Focus to focus the lens.
c. Use the focus near and far buttons to manually adjust the focus.
Configuring the Camera
Once installed, use one of the following methods to configure the camera:
l
If you have installed multiple cameras, you can use the Camera Configuration Tool to configure common
settings. For more information, see the Camera Configuration Tool User Guide.
l
If the camera is connected to the Avigilon Control Center system, you can use the client software to configure
the camera. For more information, see the Avigilon Control Center Client User Guide.
l
If the camera is connected to the Avigilon Unity Video system, you can use the client software to configure
the camera. For more information, see the Avigilon Unity Video Client User Guide.
