Page #22 background imageLoading...
Page #22 background image
Specifications
General Specifications
Maximum Capture Speed 100 km/h (62 mph)
Minimum Illumination 0 lux
IR Illumination 850 nm, continuous, field adjustable angle
Maximum IR Illumination Distance
Single Lane: 30 m (100 ft)
Dual Lane: 12 m (40 ft)
Operating Temperature Range -30 °C to 50 °C (-22 °F to 122 °F)
Cold Start Delay Up to 1.5 hours
Humidity 0 - 95%, non-condensing
Camera Specifications
The following are the specifications for the camera, 3.0C-HD-LP-B1.
Image Performance
Image Sensor 1/2.8" progressive scan CMOS
Aspect Ratio 4:3
Active Pixels 3MP: 2048 × 1536
Imaging Area 5.12 mm × 3.84 mm (0.20" × 0.15")
Maximum Image Rate 30 fps
3D Noise Reduction Filter Yes
Lens
Lens 4.7 84.6 mm, F1.6, P-Iris, remote focus and zoom
Angle of View 3.5° 59°
Image Control
Video Compression
H.264 (MPEG-4 Part 10/AVC), Motion JPEG, HDSM SmartCodec
Technology
Streaming Multi-stream H.264 and Motion JPEG
Bandwidth Management HDSM™
Motion Detection Selectable sensitivity and threshold
Iris Control Automatic, Manual
Day/Night Control Automatic, Manual
Flicker Control 50 Hz, 60 Hz
White Balance Automatic, Manual
Backlight Compensation Adjustable
Specifications 22
