Electrical specifications
For the hardware specifications, see the datasheets on page7.
Single DoorController (OP-CR-SDC) Supply Requirement: PoE, PoE+, or external 12-24VDC
Note: When using an external supply, if 24V wet relay output is
required a 24V external supply must be used.
External Supply Rating: 12V @ 2A min. or 24V @ 1A min.
Output Ratings: Power Out can supply up to 100mA @ 12V or
50mA @ 24V
2 reader ports, max power output: 250mA @ 12V each
2 relays, max power output:
PoE: Max 3W combined output (250mA @ 12V, 125mA @ 24V)
PoE+: Max 9W combined output (750mA @ 12V, 375mA @ 24V)
Electrical specifications 29
