Installation
Network requirements
An Ethernet connection with DHCP can be used to connect the Avigilon SDC to the Local Area Network (LAN).
You may also need to configure firewall settings to communicate with the Avigilon Alta access control system,
which uses the following outbound ports:
l
TCP port 443
l
UDP port 123
Note: If using an external DNS server, the outbound UDP port 53 must also be open.
To support Wi-Fi unlocking from the mobile app, the inbound TCP port 443 of the SDC must be available from
within the LAN. Inbound port forwarding on the router, firewall, or NATdevice is not required.
The SDC also supports Wi-Fi connections. Refer to Configure network settings using Open Admin app on
page20.
Power requirements
The Avigilon SDC can be powered using Power-over-Ethernet (PoE or PoE+), and/or an external 12-24V supply.
The SDC will automatically switch to the higher voltage source if both PoE and an external source are
available. We recommend using a backup battery in case of power failures on the external 12-24V supply or the
PoE supply.
Supply Requirement PoE, PoE+, or external 12-24VDC
Note: When using an external supply, if 24V wet relay output is required a 24V
external supply must be used.
External Supply Rating 12V @ 2A min. or 24V @ 1A min.
Output Ratings Power Out can supply up to 100mA @ 12V or 50mA @ 24V
2 reader ports, max power output: 250mA @ 12V each
2 relays, max power output:
PoE: Max 3W combined output (250mA @ 12V, 125mA @ 24V)
PoE+: Max 9W combined output (750mA @ 12V, 375mA @ 24V)
Installation 8
