8. DISASSEMBLY
8.1 Service Tools
8.2 Lubricants
8.3 Procedure for Disassembly and Reassembly
8.1 SERVICE TOOLS
Table 7.1 describes the maintenance tools necessary for the maintenance of this equipment.
No. Name Description
1 Minus screwdriver Idler pulley module screw
2 Philips screwdriver (magnetic) Nominal No.2 M3, M4
3 Oil Shell “Terrace Oil 46”
4 Grease Shell “Alvania Grease No.2”
5 Alcohol (Isopropyl 91% >) Cleaning
6 Digital voltmeter With 0.01 V range
7 Oscilloscope 100 MHz or more with external
sweep
8 Blower Cleaning
Table 8.1 Maintenance tools
