1. INTRODUCTION
1.1 General Notes for Servicing
1.2 General Description
1.3 Features
This manual is intended to be used by the maintenance engineers. It describes areas to be maintained,
the detailed installation, and the component replacement procedures as well as the main trouble shooting
guides.
Please take your time to read this manual thoroughly to obtain comprehensive knowledge about the
ScanCopier before serving the unit.
1.1 GENERAL NOTES FOR SERVICING
(1) Before trying to disassemble the ScanCopier, make sure the power supply code of the ScanCopier
is disconnected from the power outlet. Under any circumstance, do not remove from or install the
PWBs or connectors onto the ScanCopier with the power supply turned ON.
(2) Use caution not to drop small parts or screws inside the unit when disassembling and
reassembling. If left inside, they might cause the malfunction of the unit.
(3) Do not pull the connector cable when disconnecting it. Hold the connector.
(4) When carrying PWBs or the scanning head unit, put it in an anti-static bag.
(5) Keep the document table glass surface always clean. If contaminated, use a dry clean cloth for
cleaning.
(6) Use caution not to injure your fingers or hands when disassembling or reassembling the unit.
