AVS Electronics CAPTURE - Visualizzation; User Commands; Visualizzation

- 10 -
Visualizzation / User Commands
The User visualizations are linked to the settings made by the installer and can be of two types:
1. Flat: Allows the User to visualize the areas in groups of 16
2. Compact: Allows the User to visualize only the competing areas
in groups of 5 at the time
Description of visualization n. 2
Sector n°02: Area disarmed, balanced zones
Sector n°03: Area armed in ON
Sector n°04: Area disarmed , zones open
Sector n°06: Area armed in AREA
Sector n°08: Area armed in PERIMETER
3. Continuos: the end user can view one by one each partition and,
for the rst 16, can see the relative name
Commands:
• [][][][]: To select the area
• [ENT]: To enter the area
• [CLR]: To set directly the area number
• [0]: To manage all competing areas at the same time
• [ESC]: To step back
Visualizzation
COMPACT FLAT CONTINUOS DESCRIPTION
OK K PARTITION #01 ok Patition disarmed, zones closed
- - - PARTITION #01 -- Patition disarmed, zones opened
On O PARTITION #01 On Partition ON armed
Ho H PARTITION #01 Ho Partition HOME armed
Ar A PARTITION #01 Ar Partition AREA armed
Pe P PARTITION #01 Pe Partition PERIMETER armed
n n
- Non-competing Partition
Other messages:
These messages could be displayed on the keypad immediately or after you have entered your
user code, depending on the installer’s programming:
• SIM credit low/used up >>> recharge the SIM CARD
• Fuses >>> contact the installer
• Codes changed >>> the codes were changed
• Sensors: batt low >>> battery low sensor n° xx. We recommend you contact the installer
• Sensors: survive >>> the controller did not detect the sensor, we recommend you contact
the installer
• Sensors: antimask >>> sensor n° xx was masked and may not function correctly
• Sensors: disqualication >>> it is probably covered or misaligned, check the sensor
• Sensors: dirty lenses >>> the sensors lenses are dirty, wipe them with a cloth.
Clear messages
Messages are usually cleared automatically. Information about the GRID (power supply 220
VAC) - BATTERY (low/missing) - TELEPHONE (No telephone line) remains on the display and
is cleared by turning the system off and on.
Sector # 03 ok
Ofces
Sett. 1
knOn-AnP
Sett.: 0203040608
state:okon--arpe
