ICE KEYPAD
Description of the ICE keypad
1 MICROPHONE - FUTURE USES
2 LOGO - ACCESS TO NOTIFICATIONS CENTRE
3 ACCESS IN KEYPAD MODE
4 ACCESS IN APP MODE
5 01/11/15 13:09 SYSTEM DATE AND TIME
6 25° C TEMPERATURE DETECTED BY KEYPAD
7 LED - FUTURE USES
8
o
RED LED - POWER OFF (White) or POWER ON (Red)
9
o
GREEN LED - SYSTEM NOT READY (White) or SYSTEM READY (Green)
10 ACCESS IN QUICK ARM MODE
11 LOGO - TOY READER
12 SLOT FOR MICRO SD CARD (FOR INSTALLER)
13 MINI USB PORT (FOR INSTALLER)
01/11/15
1
3
2
4
7
8
5
6
9
10
11
12
13
