- 24 -
Enable Installer
Enables the installer to program via keypad, direct connection via USB or a remote connection via
telephone line (with EN 50131 conformity active)
Digit User Code:
Note: if the user code is associated to multiple sectors and the “Skip sector selection” option is
not active, you will be asked to select the sector to work in.
Press (1)
Press () repeatedly to the “Enable install.”
Press (ENT)
Press (ESC) key repeatedly to exit
O.C. (Open Collector) enabling
The outputs enabled, that the control panel has got, can be manually controlled and adopted for
other uses. There are two ways to operate on the active outputs; for one of the systems it is
necessary to remind the number of the output to activate/de-activate; for the other system it is
necessary to look through the reference outputs
Example: a device can be enabled or disabled either by telephone or by keypad (see this chapter)
for general applications (heating, sprinkling, ventilation, automatisms, etc.)..
Digit User Code:
Note: if the user code is associated to multiple sectors and the “Skip sector selection” option is
not active, you will be asked to select the sector to work in.
Press “output”
1° mode (a):
a Enter the number corresponding to the output to be enabled
a Press (ENT) key to conrm,
2° mode (b):
b Look through the list of the active outputs until reaching the one you wish ()
b Press (ENT) key to conrm,
b Press (ESC) key repeatedly to exit
Activation of multi-function pushbuttons
A simple operation allows to activate the functions associated to pushbuttons “A - B”, at any
time, with no need of dialling User Code.
The function associated is determined by the installer during programming and is linked to the
keypad on which the operation is made.
Dial the multi-function command (“A - B”) followed by (ENT)
