Remote Telephone Control of the system
The RTC (Remote Telephone Control) function, permits access to determined control panel
operations using a DTMF telephone connected to the telephone system or a mobile telephone.
How to call the system !
Dial the telephone number where the control panel is installed .
When the telephone has rung the number of time required, a synthesized voice will announce that
the User Code must be entered.
If an automatic answering machine is connected to the line, it can be by-passed by pro-
ceeding as follows:
a. Dial the telephone number and let the telephone ring once.
b. Hang up the receiver.
c. Dial the telephone number again at least 8 seconds later but no later than 20 seconds from the
telephone’s rst ring.
d. A synthesized voice will announce that the User Code must be entered.
Dial the User Code slowly and a synthesized voice will announce whether the User Code has been
recognized or not.
Digit the sector if required
Now the various functions can be enabled, remembering to wait until the control panel’s
two-tone signal is heard before entering each command.
DTMF Controls
• [0] OFF ZONE: Press this key to by-pass the zone(s).
Example: to by-pass zone 2;
Press these keys in the following order [0] + [2] + [#]
• [1] SECTOR: to change sector if the user is enable to operate on all S.
• [2] MEM: to see the memory events
• [3] - [4] OFF TEL: this causes the forced interruption of the telephonic communication.
• [5] OFF: control panel switch off..
• [6] O.C.: permits the control of the Open Collector outputs.
Example: in order to enable OC output number 2, press these keys in the following order [6] + [2] + [#]
(equal to the disabling procedure). The use of various O.C. outputs is generic and must be de-
termined during installation of the system.
• [7] TEST: information on the situation of the entire control panel.
• [9] ON: control panel switch on in ON mode.
• [#] ENTER: To push to conrm a data dialled on the keypad
• [à] STOP: To push to break a function (e.g. the list of the memory events)
Closing of a Communication
By use of pushbutton [3] (it activates only if “Comm. Break” is enabled in the User Prole)
it is possible to break the entire cycle of VOCAL calls pressing on pushbutton 3
By use of pushbutton [4] (always active) it is possible to break only the telephone calls addres-
sed to the telephone numbers included in the prole, pressing on pusbutton [4] during.
RTC Activation after a Communication
After having received a call and having listened to the entire message, after the bi-tone, it is pos-
sible to press on pushbutton [7] in order to activate the RTC procedure and manage the system
as it is described in the chapter referring to the “Remote Telephone Control” (it activates only
if “enables RTC” is enabled in the prole). If “Comm. Break” is enabled in the prole, it also
makes the total block of the following vocal calls..
