OWNER’S MANUAL
DVD Setup
Component input jacks on the TV
Y PB PR
Video output jacks of DVD player
Y Pb Pr
Y B-Y R-Y
Y Cb Cr
Y P
B PR
How to connect a DVD (digital video disk player)
• Connect DVD video inputs to Y, Pb, Pr of COMPONENT (DVD/DTV INPUT) and audio inputs to Audio
jacks of AV INPUT.
• Component Input is available to 480/576i, 480/576p, 720p, 1080i mode.
How to use
• Press TV/AV button on the remote control of the TV to select COMPONENT. Use the DVD player
according to its owner’s manual.
• Turn on the DVD player, and insert a DVD.
• Component Input ports
Connect DVD player jacks to TV Component input jacks as indicated below.
