Axis 221 User Manual

49
AXIS 221 - Technical Specifications
Power 7-24 V DC, max 5.5 W (without I/O)
10-24 V AC, max 7.5 VA (without I/O)
Power over Ethernet (IEEE 802.af) with power classification according to Class 2
(3.84 to 6.49W) connection via RJ-45 network cable
Operating conditions 5 - 50 ºC (41 – 122 ºF), humidity 20 - 80% RH
Temperature warning Warning issued when temperature is below or above operating conditions (see
above)
Management and
maintenance
Support for configuration backup and restore
Support for firmware upgrades over HTTP or FTP, firmware available at
www.axis.com
Video access from web
browser
Camera live view, sequence tour capability for up to 20 Axis cameras,
customizable HTML pages
System requirements Pentium III CPU 500 MHz or higher, or equivalent AMD, 128 MB RAM
AGP graphic card, Direct Draw, 32 MB RAM
DirectX 9.0 or later
Supported Operating Systems Windows (XP, 2000) Linux, Mac OS X.
Supported Web Browsers For Windows - Internet Explorer 5.x or later, Mozilla 1.4* or later.
For Linux - Mozilla 1.4* or later.
For Mac OSX - Mozilla 1.4* or later, Netscape 7.1* or later.
* = limited functionality
Required protocol Standard TCP/IP protocol suite
Supported protocols HTTP, HTTPS, SSL/TLS*, SNMP-v1-2c-3 MIB-II, RTP, NTP, BOOTP, UDP, IGMP, RTCP,
SMTP, FTP, DHCP, UPnP, ARP, DNS, DynDNS, SOCKS v.4.0/v.5.0. More information
on protocol usage available at www.axis.com
*This product includes software developed by the Open SSL Project for use in the
Open SSL Tool kit (http://www.openssl.org/)
Complimentary software AXIS Media Control (AMC) - ActiveX component software required for Microsoft
Internet Explorer - installed automatically on first use
Optional: AXIS IP Utility - for installation in Windows.
Available applications
(not incl.)
AXIS Camera Station - Surveillance application for viewing, recording and
archiving up to 25 cameras
AXIS Camera Recorder - Surveillance application for viewing and recording up to
16 cameras
AXIS Camera Explorer – Basic software for viewing and manual recording
See www.axis.com/partner/adp_partners.htm for more software applications via
partners
Included accessories Power supply 9 V DC, stand, connector kit, Installation Guide, CD-ROM with
installation tool, software, User’s Manual, MPEG-4 licenses (1 encoder, 1
decoder), MPEG-4 decoder (Windows)
Available accessories
(not incl.)
IP65-rated outdoor housings for installation outdoors or in adverse indoor
environments
Power over Ethernet midspans
AXIS 292 Network Video Decoder
AXIS MPEG-4 Decoder 10 user license pack
Item Specification

Axis 221 Specifications

General

Maximum resolution	640 x 480 pixels
Supported video modes	-
Video formats supported	MPEG4
Camera shutter speed	1/25000 - 2 s
Minimum illumination	0.08 lx
Sensor type	CCD
Progressive scan	Yes
Optical sensor size	1/3 \
Optical zoom	- x
Focus adjustment	1.0
Focal length range	3 - 8 mm
Built-in HDD	No
Flash memory	8 MB
Internal memory	32 MB
Type	IP security camera
Certification	EN 55022 B, EN 55024, EN 61000-3-2, EN 61000-3-3, \\r EN 61000-6-1, EN 61000-6-2, FCC 5 B B, \\r VCCI B, C-tick AS/NZS CISPR22, ICES-003 B, \\r EN 60950-1
Placement supported	Indoor
Connectivity technology	Wired
Form factor	Bullet
Product color	Gray
Housing material	Aluminum
Ethernet LAN (RJ-45) ports	1
Cabling technology	10/100Base-T(X)
Supported network protocols	IPv4/v6, HTTP, HTTPS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
AC input voltage	24 V
Power source type	PoE
Power consumption (typical)	7.5 W
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	20 - 80 %
Compliance industry standards	IEEE 802.3a

Weight and Dimensions

Weight	550 g
