Axis 221 User Manual

50
AXIS 221 - Technical Specifications
Approvals EMC: EN55024:1998 + A1 + A2
EN61000-6-1:2001
EN61000-6-2:2001
EN55022: 1998 + A1 Class B
EN61000-3-2:2000
EN61000-3-3:1995 + A1
FCC Part 15 Subpart B Class B by compliance with EN55022:1998 Class B
VCCI:2003 Class B ITE
C-tick AS/NZS 3548
Canadian ICES-003 B by compliance with EN55022:1998 Class B
Approvals - Safety EN60950
UL
CSA
MTBF 100,000 hours
Dimensions (HxWxD)
and weight
49 x 88 x 186 mm (1
15
/
16” x 3
15
/
32” x 7
5
/
16”)
550 g (19
13
/
32 oz) excl. power supply
Item Specification

Axis 221 Specifications

General

Maximum resolution	640 x 480 pixels
Supported video modes	-
Video formats supported	MPEG4
Camera shutter speed	1/25000 - 2 s
Minimum illumination	0.08 lx
Sensor type	CCD
Progressive scan	Yes
Optical sensor size	1/3 \
Optical zoom	- x
Focus adjustment	1.0
Focal length range	3 - 8 mm
Built-in HDD	No
Flash memory	8 MB
Internal memory	32 MB
Type	IP security camera
Certification	EN 55022 B, EN 55024, EN 61000-3-2, EN 61000-3-3, \\r EN 61000-6-1, EN 61000-6-2, FCC 5 B B, \\r VCCI B, C-tick AS/NZS CISPR22, ICES-003 B, \\r EN 60950-1
Placement supported	Indoor
Connectivity technology	Wired
Form factor	Bullet
Product color	Gray
Housing material	Aluminum
Ethernet LAN (RJ-45) ports	1
Cabling technology	10/100Base-T(X)
Supported network protocols	IPv4/v6, HTTP, HTTPS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
AC input voltage	24 V
Power source type	PoE
Power consumption (typical)	7.5 W
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	20 - 80 %
Compliance industry standards	IEEE 802.3a

Weight and Dimensions

Weight	550 g
