2
Contents
Important safety instructions 4
Usage conditions and restrictions 4
Electrical safety, power cord and plug 5
Position 5
Cleaning and maintenance 5
Accessories 7
Connections and functions 8
Remote control 9
Wall mounting instructions 13
Basic installation 14
First time setup 17
Installing The Batteries 18
Using the Remote Control 18
Selecting an Input Source 19
Operating The Menus 20
Picture Menu 20
Sound Menu 23
Channel Menu 26
Lock Menu 31
33
34
36
36
36
36
37
38
39
39
40
Hotel Mode
Setup Menu
PVR and Time Shift Operation
PVR Setting
First Time Setup
Reset
USB Device Setup
Timeshift
Instant Recording
Time Recorder
Playlist
3
Contents
USB Multimedia Playback Format 46
DVD Function 48
System setup 48
Audio setup 49
Preference page 50
FAQs 51
EPG (Electronic Program Guide) 41
ATV / HDMI / AV / YPbPr / PC 42
Multi Media Menu Operation 43
Photo 43
Music 44
Movie 44
Text 45
MODEL AX-1519 AX-1522 AX-1524
Panel System 18.5”/21.5”/24” LED panel with Built-in DVD Player
Display Resolution 1366x768
Television System PAL/SECAM
Inputs/Outputs
HDMI input 1
PC 640x480/60Hz 800x600/60Hz 1024x768/60Hz
1366x768/60Hz 1920x1080/60Hz
Audio (AV/PC) R/L 200mVrms (max3.0vp-p) 20K RCA
Audio R/L 200mVrms (max3.0vp-p) 20K
Video Video 1.0 Vp-p 75
Audio L/R R/L 200mVmrs (max3.0Vp-p) 20K
Speaker consumption L/R 2x3W
Voltage DC12V 3A
Power consumption 26W 36W32W
Mobile Mounting 100 x 100 VESA
Specifications
