35
AXIS M3014 - System Options
QoS Settings - For each type of network traffic supported by your Axis network video product, enter a DSCP
(Differentiated Services Codepoint) value. This value is used to mark the traffic’s IP header. When the marked traffic reaches a
network router or switch, the DSCP value in the IP header tells the router or switch the type of treatment to apply to this type
of traffic, for example, how much bandwidth to reserve for it. Note that DSCP values can be entered in decimal or hex form,
but saved values are always shown in decimal.
For more information on Quality of Service,
please see the Axis support web at www.axis.com/techsup
SMTP (email)
Enter the host names (or IP addresses) and port numbers for your primary and secondary mail servers in the fields provided, to
enable the sending of notifications and image email messages from the camera to predefined addresses via SMTP.
If your mail server requires authen
tication, check the box for Use authentication to log in to this server and enter the
necessary information. See the online help for more information.
SNMP
The Simple Network Management Protocol (SNMP) allows remote management of network devices. An SNMP community is
the group of devices and management station running SNMP. Community names are used to identify groups.
Depending on the level of security required, select the version of SNMP to use. The
three levels of security are:
SNMP v1/v2
Select either SNMP V1 that includes no security, or SNMP V2c
that uses very simple security.
The community name can be specified as a password for read or read/write access to all supported SNMP objects. The
community is the group of network devices using SNMP. The default password for the Read Community is public and the
default password for the Write community is write.
Traps for SNMP v1/v2
Traps are used by the camera to send messages to a manage
ment system for important events or status changes.
If En
able traps is selected, enter the email address where the trap message is to be sent as well as the Trap community that
should receive the message.
There are four types of traps available for the AXIS M3014.
Cold start
•Warm start
•Link up
Authentication failed
SNMP v3
SNMP V3 provides encryption and secure passwords. HTTPS
must be enabled. To use traps with SNMP v3 an SNMP v3
management application is required.
If the Enable S
NMP v3 option is enabled, provide the Initial user password. Note that the initial password is activated only
when HTTPS is enabled and can only be set once.
If HTTPS is enabled, SNMP v1 and
SNMP v2c should be disabled.
When SNMP configuration is ready, click Save to u
se the new settings or Reset to return to the default values.
UPnP™
The network camera includes support for UPnP™. UPnP™ is enabled by default, and the network camera then is automatically
detected by operating systems and clients that support this protocol.

Other manuals for Axis M3014

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Axis M3014 and is the answer not in the manual?

Axis M3014 Specifications

General IconGeneral
Total megapixels1 MP
Maximum resolution1280 x 800 pixels
Video formats supportedH.264, M-JPEG
Minimum illumination1 lx
Sensor typeCMOS
Progressive scanYes
Optical sensor size1/4 \
Effective sensor resolution1000000 pixels
Lens diameter2.9 mm
Cabling technology10/100Base-T(X)
Supported network protocolsIPv4/v6, HTTP, HTTPS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Power source typePoE
Ethernet LAN (RJ-45) ports1
CertificationEN 55022 B, EN 61000-3-2, EN 61000-3-3, EN 55024, FCC Part 15 Subpart B B, ICES-003 B, VCCI B, C-tick AS/NZS CISPR 22, MIC B, EN 60950-1 AXIS M3014: KCC B
Processor modelARTPEC-3
Placement supportedIndoor & outdoor
Mounting typeCeiling
Flash memory128 MB
Operating temperature (T-T)0 - 45 °C
Operating relative humidity (H-H)20 - 80 %
Weight and Dimensions IconWeight and Dimensions
Weight260 g
