AXIS M3014 - Technical Specifications
Technical Specifications
Function/group Item Specification
Camera Models AXIS M3014
Image sensor ¼” Progressive scan RGB CMOS 1 Megapixel
Lens • 2.9 mm, F2.0
• Horizontal angle of view: 80°
• Vertical angle of view: 48°
• Diagonal angle of view: 100°
Light sensitivity 1 lux, F2.0
Shutter time 1/245000 s to 1/6 s
Pan/Tilt/Zoom Digital PTZ, preset positions, guard tour
Video Video compression • H.264
• Motion JPEG
• H.264 Baseline profile
Resolutions 1280x800 to 160x100
Frame rate H.264 30 fps in all resolutions
Frame rate
Mot
ion JPEG
30 fps in all resolutions
Video streaming • Multi-stream H.264 and Motion JPEG
• 1 stream in full frame rate at highest resolution in either H.264, Motion
JPEG or both
• Controllable frame rate and bandwidth
• VBR/CBR H.264
Image settings • Compression, color level, brightness, sharpness, contrast, white balance,
exposure value, exposure control, exposure zones, backlight compensation,
fine tuning of behavior at low light
• Rotation
• Mirroring
• Text and image overlay
• Privacy mask
Network Security • Password protection, IP address filtering, HTTPS encryption, digest
authentication, user
access log
Supported protocols IPv4/v6, HTTP, HTTPS*, SSL/TLS*, QoS Layer 3
DiffServ, FTP, SMTP, Bonjour,
UPnP, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP,
IGMP, RTCP, ICMP, DHCP, ARP, SOCKS.
*This product includes software developed by the
Open SSL Project for use in
the Open SSL Tool kit (www.openssl.org)
System
I
ntegration
Application
Programming
Interface
• Open API for software integration, including VAPIX® from Axis
Communications*, AXIS Media Control SDK*, event trigger data in video
stream, ONVIF specification available at www.onvif.org
• Quality of Service (QoS) la
yer 3, DiffServ Model
• Embedded Linux operating system
• Support for AXIS Video Hosting System (AVHS)
with One-Click Camera
connection
*Available at www.axis.com
Intelligent Video Video motion detection, active tampering alarm
Support for AXIS Camera Application Platform enabling
installation of additional applications
Alarm triggers • Intelligent video
• On reboot
• Manual trigger
Alarm events • File upload via FTP, HTTP and email
• Notification via email, HTTP and TCP

Axis M3014 Specifications

General

Total megapixels	1 MP
Maximum resolution	1280 x 800 pixels
Video formats supported	H.264, M-JPEG
Minimum illumination	1 lx
Sensor type	CMOS
Progressive scan	Yes
Optical sensor size	1/4 \
Effective sensor resolution	1000000 pixels
Lens diameter	2.9 mm
Cabling technology	10/100Base-T(X)
Supported network protocols	IPv4/v6, HTTP, HTTPS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Power source type	PoE
Ethernet LAN (RJ-45) ports	1
Certification	EN 55022 B, EN 61000-3-2, EN 61000-3-3, EN 55024, FCC Part 15 Subpart B B, ICES-003 B, VCCI B, C-tick AS/NZS CISPR 22, MIC B, EN 60950-1 AXIS M3014: KCC B
Processor model	ARTPEC-3
Placement supported	Indoor & outdoor
Mounting type	Ceiling
Flash memory	128 MB
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Weight	260 g
