Axis M3014 User Manual

20
AXIS M3014 - Live View Config
Viewer Settings
Check the Show viewer toolbar box to display the AXIS Media Control (AMC) or the QuickTime viewer toolbar under the video
image in your browser.
The administrator can disable the installation of the H
.264 decoder included with AMC. This is used to prevent the installation
of unlicensed copies. Further decoder licenses can be purchased from your Axis dealer.
The Show
crosshair in PTZ joystick mode shows up a cross that indicates the center of the image when viewing the video
stream in PTZ joystick mode.
You can set the PTZ mode to joystick. Check the Use
PTZ joystick mode as default option.
Check the Enable rec
ording button to enable recording from the Live View page.
Action Buttons
The Show manual trigger button can be used to manually trigger and stop an event from the Live View page. See Events, on
page 23.
Check the Show snapsho
t button to save a snapshot from the video stream. This button is mainly intended for use with
browsers other than Internet Explorer, or when not using AXIS Media Control (AMC) to view the video stream. AMC for
Internet Explorer provides its own snapshot button.
User Defined Links
User defined links can be CGI links or web links. Once configured,
the link(s) appear on the Live View page.
To set up a web link, select the U
se as web link radio button,
enter a descriptive name and enter the URL in the field. Click Save
and the link appears in the Live View page.
User defined CGI links can be used to issue VAPIX API requests.
For more information on the VAPIX App
lication Programming
Interface (API), see the Support/Network Video/Developer pages
on the Axis Web site at http://www.axis.com
Please use the online help files for more information.
User defined Link

Axis M3014 Specifications

General

Total megapixels	1 MP
Maximum resolution	1280 x 800 pixels
Video formats supported	H.264, M-JPEG
Minimum illumination	1 lx
Sensor type	CMOS
Progressive scan	Yes
Optical sensor size	1/4 \
Effective sensor resolution	1000000 pixels
Lens diameter	2.9 mm
Cabling technology	10/100Base-T(X)
Supported network protocols	IPv4/v6, HTTP, HTTPS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Power source type	PoE
Ethernet LAN (RJ-45) ports	1
Certification	EN 55022 B, EN 61000-3-2, EN 61000-3-3, EN 55024, FCC Part 15 Subpart B B, ICES-003 B, VCCI B, C-tick AS/NZS CISPR 22, MIC B, EN 60950-1 AXIS M3014: KCC B
Processor model	ARTPEC-3
Placement supported	Indoor & outdoor
Mounting type	Ceiling
Flash memory	128 MB
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Weight	260 g
