26
AXIS M3014 - Events
Motion Detection
Motion detection is used to generate an alarm whenever movement occurs (or stops) in the video image. It is possible to
configure a total of 10 windows (Include and Exclude) for motion detection.
• Inclu
ded windows target specific areas within the whole video image
• Excl
uded windows define areas within an Include window that should be ignored (areas outside Include windows are
automatically ignored)
Once configured, the motion detection windows appear in the list of available triggers, for triggering events. See How to set
up a triggered event, on page
24.
Note:
Using the motion detection feature may decrease the camera’s overall performance.
Configuring Motion Detection
1. Click Motion Detection in the Events menu.
2. Select one of the following options - Configure Included Windows, or Configure Excluded Windows.
3. Click on New against Windows Name and enter a descriptive name in the field below.
4. Adjust the size (drag the bottom right-hand corner) and position (click on the text at the top and drag to the desired
position) of the active window.
5. Adjust the Object Size, History and Sensitivity profile sliders (see table below for details). Any detected motion within
an active window is then indicated by red peaks in the Activity window (the active window has a red frame).
6. Click Save.
See the online help for descriptions of each available option.
To exclude parts of the Include window, select the Exclude option and position the
Exclude window as required, within the Include window.
