Axis M3014 User Manual

27
AXIS M3014 - Events
Examples:
• Avoid triggering on small objects in the video image by setting the object size level to high.
• Use several small Motion Detection windows rather than one large window, if triggers on small movements or
objects are desired.
• To reduce the number of triggers if there is a lot of movement during a short period of time, select a high history
level.
• To only detect flashing light, select low sensitivity. In other cases, a high sensitivity level is recommended.
Object Size History Sensitivity
High level Only very large objects
trigger motion detec-
tion
An object that appears in the region
will trigger the motion detection for
a long period
Ordinary colored objects on ordinary
backgrounds will trigger the motion
detection
Low level Even very small objects
trigger motion detec-
tion
An object that appears in the region
will trigger motion detection for only
a very short period
Only very bright objects on a dark
background trigger motion detection
Default value Low High High

Axis M3014 Specifications

General

Total megapixels	1 MP
Maximum resolution	1280 x 800 pixels
Video formats supported	H.264, M-JPEG
Minimum illumination	1 lx
Sensor type	CMOS
Progressive scan	Yes
Optical sensor size	1/4 \
Effective sensor resolution	1000000 pixels
Lens diameter	2.9 mm
Cabling technology	10/100Base-T(X)
Supported network protocols	IPv4/v6, HTTP, HTTPS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Power source type	PoE
Ethernet LAN (RJ-45) ports	1
Certification	EN 55022 B, EN 61000-3-2, EN 61000-3-3, EN 55024, FCC Part 15 Subpart B B, ICES-003 B, VCCI B, C-tick AS/NZS CISPR 22, MIC B, EN 60950-1 AXIS M3014: KCC B
Processor model	ARTPEC-3
Placement supported	Indoor & outdoor
Mounting type	Ceiling
Flash memory	128 MB
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Weight	260 g
