AXIS M3014 - Video
Privacy mask
Privacy masks are up to three configurable areas of solid color that allow concealment of parts of the image that are not to be
viewable. Privacy masks cannot even be bypassed via the VAPIX® Application Programming Interface (API). The Privacy Mask
List shows all the masks that are currently configured in AXIS M3014 Network Camera and indicates if they are enabled. To
define a new mask:
1. Click Add. A
rectangle appears on the image.
1. Place the rectangle over the desired area to conceal.
2. To resize, click and pull the bottom right-hand corner.
3. Choose a color, black, white, gray or red for the box from the Privacy mask color drop-down list.
4. Enter a descriptive name in the Mask name field.
5. Click Save.
To edit a privacy mask, select it and reshap
e, move or change color as needed. Refer to the online Help for more
information.

Axis M3014 Specifications

General

Total megapixels	1 MP
Maximum resolution	1280 x 800 pixels
Video formats supported	H.264, M-JPEG
Minimum illumination	1 lx
Sensor type	CMOS
Progressive scan	Yes
Optical sensor size	1/4 \
Effective sensor resolution	1000000 pixels
Lens diameter	2.9 mm
Cabling technology	10/100Base-T(X)
Supported network protocols	IPv4/v6, HTTP, HTTPS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Power source type	PoE
Ethernet LAN (RJ-45) ports	1
Certification	EN 55022 B, EN 61000-3-2, EN 61000-3-3, EN 55024, FCC Part 15 Subpart B B, ICES-003 B, VCCI B, C-tick AS/NZS CISPR 22, MIC B, EN 60950-1 AXIS M3014: KCC B
Processor model	ARTPEC-3
Placement supported	Indoor & outdoor
Mounting type	Ceiling
Flash memory	128 MB
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Weight	260 g
