Axis Q6034 User Manual

AXIS Q6034 PTZ Dome Network Camera
Accessing the Product
The Live V iew Page
The controls and layout of the Live View page may have been customized to meet specific installation requirements and user
preferences. Consequently, some of the examples and functions featured here may differ from those displayed in your own Live View
page. The following provides an overview of each available control.
Controls on the Live View Page
The Stream Profile drop-down list allows you to select a custom ized or pre-pro grammed stream profile. Stream
profiles are configured under Video & Audio > Stream Profiles.See
Stream Profiles, on page 18 .
Click Pulse to activate the output for a defined pe riod of time, such as switching on an external light for 20 seconds.
Click the Active/Inactive buttons to manually start and stop a connected device — e.g. switch an external light
on and off.
The Manual Trigger button is used to trigger an action rule from the Live View page; see . Enable this button
from Live View Config > Action Buttons.
Click Snapshot to save a snapshot of the video image. Right-click the video image to save it in JPEG format on your
computer. This button is p rimarily intended for use when the AXIS Media Co ntrol viewer toolbar is not available.
Enable this button from Live View Config > Action Buttons.
The Audio clip drop-down list allows y ou to play an audio clip from the Live View page. Select the aud io
clip and click the Play button.
Activate the product’s fans with this button. Enable this button from Live View Config > Action Buttons. The Fan
button is activated automatically. Press this button to activate it manually.
Enable or disable the Gatekeeper by selecting On or Off from the drop-down list. See page 29 for more information
about Gatek eeper.
AXIS Media Control viewer toolbar
The AXIS Media Contro l viewer toolbar is avail
able in Internet Explorer only. See
AXIS Media Control (AMC), on page 13 for more
information. The toolbar displays the following buttons:
The Play button connects to the Axis product and starts playing a m edia stream.
The Stop button stops the media stream
.
The Snapshot button takes a s
napshot of the video image. The location where the image is saved can be specified
in the AMC Control Panel.
10

Axis Q6034 Specifications

General

Maximum resolution	1280 x 720 pixels
Video formats supported	H.264
Pan range	0 - 360 °
Tilt angle range	0 - 180 °
Camera shutter speed	1/10000 - 1/4 s
Digital zoom	12 x
Optical zoom	18 x
Focal length range	4.7 - 84.6 mm
Video motion detection	Yes
Sample rate	16 kHz
Supported network protocols	IPv4/v6, HTTP, HTTPS, SSL/TLS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Dimensions (WxDxH)	198 x 198 x 240 mm
Power requirements	100 - 240 V AC
Power source type	PoE
Power consumption (typical)	17 W
Certification	EN 55022 Class B, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, EN 55024, FCC Part 15 Subpart B Class B, ICES-003 Class B, VCCI Class B, C-tick AS/NZS CISPR 22, KCC Class B, IP52, IEC 60721-4-3 Class 3K3, 3M3, EN/IEC 60068-2
Processor model	ARTPEC-3
Flash memory	128 MB
Internal memory	256 MB
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Weight	2600 g
