Axis Q6034 User Manual

AXIS Q6034 PTZ Dome Network Camera
Accessing the Product
Accessing the Product
To install the Axis product, refer to the Installation Guide supplied with the product.
The product can be used with most operating systems and browsers. The recommended bro wsers are Internet Explorer with Windows,
Safari with Macintosh and Firefox with other operating systems. See
Technical Specifications, on page 57 .Toviewstreamingvideoin
Internet Explorer, allow ins tallation o f AXIS Media Control (AMC) when prompted.
Note
• QuickTime
TM
is also supported for viewing H.264 streams and for audio.
• If your computer restricts the use of additional software components, the product can be configured to use a Java
applet for viewing Motion JPEG.
Access from a Browser
1. Start a browser (Internet Explorer, Firefox, Safari).
2. Enter the IP address or host name of the Axis product in the browser’s Location/Address field. To access the product from a
Macintosh computer (Mac OS X), click on the Bonjour tab and select the product from the drop-down list.
If you do n ot know the IP address, use AXIS IP Utility to locate the product on the network. For more information on how to
discover and assign an IP ad dress, refer to the Installation Guide.
3. Enter your user name and p assword. If this is the first time t he product is accessed, the root password must first be
configured; for instructions see
Set the Root Password, on page 9 .
4. The product’s Live View page appears in y our browser.
Note
The controls and layout of the Live View page may have been customiz ed to meet specific installation requirements and
user preferences. Consequently, some of the example s and functions featured here may differ from those displayed in
your own Live View page.
8

Axis Q6034 Specifications

General

Maximum resolution	1280 x 720 pixels
Video formats supported	H.264
Pan range	0 - 360 °
Tilt angle range	0 - 180 °
Camera shutter speed	1/10000 - 1/4 s
Digital zoom	12 x
Optical zoom	18 x
Focal length range	4.7 - 84.6 mm
Video motion detection	Yes
Sample rate	16 kHz
Supported network protocols	IPv4/v6, HTTP, HTTPS, SSL/TLS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Dimensions (WxDxH)	198 x 198 x 240 mm
Power requirements	100 - 240 V AC
Power source type	PoE
Power consumption (typical)	17 W
Certification	EN 55022 Class B, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, EN 55024, FCC Part 15 Subpart B Class B, ICES-003 Class B, VCCI Class B, C-tick AS/NZS CISPR 22, KCC Class B, IP52, IEC 60721-4-3 Class 3K3, 3M3, EN/IEC 60068-2
Processor model	ARTPEC-3
Flash memory	128 MB
Internal memory	256 MB
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Weight	2600 g
