AXIS Q6034 PTZ Dome Network Camera
Setting Up the Product
Setting Up the Product
The Axis product can be configured by u sers with administra tor or operator rights. To open the product’s Setup pages, click Setup in
the top right-hand corner of the Live View page.
• Administrators have unrestricted access to all settings.
• Operators have access to all settings except System Options
See also the online help
.
Basic Setup
Basic Setup provides shortcuts to the settings thatshouldbemadebeforeusingtheAxisproduct:
1. Users. See
page 41 .
2. TCP/IP. See
page 43 .
3. Date & Time. See
page 42 .
4. Video Stream. See
page 17 .
5. Audio Settings. See
page 21 .
The Basic Setup menu can be disabled from System Options > Security > U sers.
16

Axis Q6034 Specifications

General

Maximum resolution	1280 x 720 pixels
Video formats supported	H.264
Pan range	0 - 360 °
Tilt angle range	0 - 180 °
Camera shutter speed	1/10000 - 1/4 s
Digital zoom	12 x
Optical zoom	18 x
Focal length range	4.7 - 84.6 mm
Video motion detection	Yes
Sample rate	16 kHz
Supported network protocols	IPv4/v6, HTTP, HTTPS, SSL/TLS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Dimensions (WxDxH)	198 x 198 x 240 mm
Power requirements	100 - 240 V AC
Power source type	PoE
Power consumption (typical)	17 W
Certification	EN 55022 Class B, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, EN 55024, FCC Part 15 Subpart B Class B, ICES-003 Class B, VCCI Class B, C-tick AS/NZS CISPR 22, KCC Class B, IP52, IEC 60721-4-3 Class 3K3, 3M3, EN/IEC 60068-2
Processor model	ARTPEC-3
Flash memory	128 MB
Internal memory	256 MB
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Weight	2600 g
