AXIS Q6034 PTZ Dome Network Camera
Hardware Overview
Hardware Overview
1
2
3
4
5
6
7
1
Part number (P/N) & Serial number (S/N)
2
Network co nnector (PoE+)
3
Multi-connector
4
SD card slot (SDHC)
5
Status LED indicator
6
Control b utton
7
Power button
Connectors
For technical sp
ecifications, see
page 57 .
Network con
nector - RJ-45 Ethernet connector. Supports Power over Ethernet Plus (PoE+) IEEE 802.3at. Use the supplied midspan.
NOTICE
Due to l
ocal regulations or the environmental and electrical conditions in which the product is to be used , a shielded network
cable (STP) may be appropriate or required. Any network cables that are routed in outdoor enviro nments or similar shall be
shielded (STP) and intended for their specific use. Make sure that the midspan is properly grounded. See
Electromagnetic
Com
patibility (EMC)
for regulatory requirements.
6

Axis Q6034 Specifications

General

Maximum resolution	1280 x 720 pixels
Video formats supported	H.264
Pan range	0 - 360 °
Tilt angle range	0 - 180 °
Camera shutter speed	1/10000 - 1/4 s
Digital zoom	12 x
Optical zoom	18 x
Focal length range	4.7 - 84.6 mm
Video motion detection	Yes
Sample rate	16 kHz
Supported network protocols	IPv4/v6, HTTP, HTTPS, SSL/TLS, QoS Layer 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Dimensions (WxDxH)	198 x 198 x 240 mm
Power requirements	100 - 240 V AC
Power source type	PoE
Power consumption (typical)	17 W
Certification	EN 55022 Class B, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, EN 55024, FCC Part 15 Subpart B Class B, ICES-003 Class B, VCCI Class B, C-tick AS/NZS CISPR 22, KCC Class B, IP52, IEC 60721-4-3 Class 3K3, 3M3, EN/IEC 60068-2
Processor model	ARTPEC-3
Flash memory	128 MB
Internal memory	256 MB
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Weight	2600 g
