Axis Q6035 User Manual

AXIS Q6035 PTZ Dome Network Camera
PTZ (Pan Tilt Zoom)
the most movement will be followed. Autotracking continues until the moving object stops or disappears from the mo nitored area.
Movement in areas blocked by privacy ma sks and in e xclude areas does not trigger autotracking.
It is strongly recommended to enable the PTZ Control Queue if autotracking and g uard tour are enabled simultaneously. In the PTZ
Control Queue, guard tour has lower priority than autotracking, so autotracking will not be abandoned to start a guard tour.
Configuration
Start/Stop Autotracking - Click Start to enable autotracking. To disable autotracking, click Stop.
Settings - The Movement trigger sensitivity level can be set to Low, Medium or High. Medium is usually a good choice, depending on
the size of the moving objects and the image contrast, a low or high sensitivity might be more suitable.
Exclude Areas
Exclude areas are areas where movement is to be ignored.
Note
Movement in an area blocked by a privacy mask is always ignored.
1. Click Add area to create an exclude area
2. Resize and move the area (the blue rectangle) to the desired position.
3. Enter a descriptive name and click Save.
To remove an area, click the name of the area and click Remo ve. To enable or disable an area, click the name of the a rea and
click Enable/Disable.
Max Limits
The pan an d tilt limits restrict the area where autotracking is allowed. This may prov
e useful, for example, to avoid tracking
birds in the sky.
1. Select Enable tilt limit and Enable tilt limit respe c tively to enable the pan and tilt limits.
2. Enter the Tilt angle and Pan limit values.
3. Click Save.
Top view
Autotracking allowed
Guard Tour
A guard tour displays the video stream from different preset po sitions, one-by-one, in a predetermined order or at random and for
configurable time periods. The enabled guard tour will keep running after the user has logged off or closed the browser.
The guard tour function in this Axis product also includes tour recording, see
Tour recording, on page 26 .
25

Axis Q6035 Specifications

General

Maximum resolution	1920 x 1080 pixels
Supported video modes	1080p, 720p
Video formats supported	H.264, M-JPEG, MPEG4
Supported graphics resolutions	1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Pan range	0 - 360 °
Tilt angle range	0 - 180 °
Camera shutter speed	1/30000 - 1/4 s
Minimum illumination	0.04 lx
Sensor type	CMOS
Optical sensor size	1/2.8 \
Digital zoom	12 x
Optical zoom	20 x
Focus adjustment	1.6 - 3.5
Focal length range	4.7 - 94 mm
Security algorithms	802.1x RADIUS
Video motion detection	Yes
Certification	EN 55022 B, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, EN 55024, FCC 15 B B, ICES-003 B, VCCI B, C AS/NZS CISPR 22, IEC 60529 IP52, IEC 60721-4-3 Class 3K3, 3M3 GS, UL, cUL, CE, FCC, VCCI, CB, KCC, UL-AR
Processor model	ARTPEC-3
Placement supported	Indoor
Connectivity technology	Wired
Built-in HDD	No
Flash memory	128 MB
Internal memory	256 MB
Compatible memory cards	SD, SDHC
Form factor	Dome
Product color	White
Housing material	Metal
International Protection (IP) code	IP52
Headphone outputs	1
Audio formats supported	AAC, MS-ADPCM, PCM
Cabling technology	10/100Base-T(X)
Supported network protocols	IPv4/v6, HTTP, HTTPS*, QoS 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Compliance industry standards	802.3at
AC input voltage	100-240 V
Power source type	PoE
AC input frequency	50 Hz
Power consumption (typical)	30 W
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Width	198 mm
Height	240 mm
Weight	2600 g
