AXIS Q6035 PTZ Dome Network Camera
Accessing the product
Configure capture mode
Capturemodedefines how image data is taken from the image sensor in regards to resolution and frame rate, prioritizing either one
or the other. C apture mode is set the first time the product is accessed. Select the desired Capture Mode from the drop-down list
and click OK.Seealso
Capture mode, on page 16
The Live View page
If the Axis product has been customized to meet specific requirements, not all the items described below will appear in the Live View
page. The following provides an overview of each available button.
Controls on the Live View page
The Stream Profile drop-down list allows you to select a customized or pre-programmed stream profi le. Stream
profiles are configured under Video & Audio > Stream Profiles.See
Stream Profiles, on page 16 .
Click Pulse to activate the output for a defined period of time, such as switching a light on for 20 seconds.
Click the Active/Inactive buttons to manually start and stop a connected device — e.g. switch a light on and off.
The Manual Trigger button can trigger an event directly from th
eLiveViewpage.Thebuttonisconfigured under
Live View Config > Action Buttons.
Click Snapshot to save a snapshot of the video image. Right-click the video image to save it in JPEG format on your
computer. This button is primarily intended for use when the AXIS Media Control vie w er toolbar is not available.
Enable this button from Live View Confi
g > Action Buttons.
Activate the product’s fans with t
his button. Enable this button from Live View Config > Action Buttons. The Fan
button is a ctivated automatically. Press this button to activate it manually.
Enable or disable the Gat
ekeeper by selecting On or Off from the drop-down list. The Gatekeeper is configured
under Setup > Events > Gatekeeper,see
page 33 .
AXIS Media Control viewer toolbar
The AXIS Me dia Control viewe r toolbar is available in Internet Explorer only. See AXIS Media Control (AMC), on page 11 for more
information. The toolbar displays the following buttons:
8

Axis Q6035 Specifications

General

Maximum resolution	1920 x 1080 pixels
Supported video modes	1080p, 720p
Video formats supported	H.264, M-JPEG, MPEG4
Supported graphics resolutions	1280 x 720 (HD 720), 1920 x 1080 (HD 1080)
Pan range	0 - 360 °
Tilt angle range	0 - 180 °
Camera shutter speed	1/30000 - 1/4 s
Minimum illumination	0.04 lx
Sensor type	CMOS
Optical sensor size	1/2.8 \
Digital zoom	12 x
Optical zoom	20 x
Focus adjustment	1.6 - 3.5
Focal length range	4.7 - 94 mm
Security algorithms	802.1x RADIUS
Video motion detection	Yes
Certification	EN 55022 B, EN 61000-3-2, EN 61000-3-3, EN 61000-6-1, EN 61000-6-2, EN 55024, FCC 15 B B, ICES-003 B, VCCI B, C AS/NZS CISPR 22, IEC 60529 IP52, IEC 60721-4-3 Class 3K3, 3M3 GS, UL, cUL, CE, FCC, VCCI, CB, KCC, UL-AR
Processor model	ARTPEC-3
Placement supported	Indoor
Connectivity technology	Wired
Built-in HDD	No
Flash memory	128 MB
Internal memory	256 MB
Compatible memory cards	SD, SDHC
Form factor	Dome
Product color	White
Housing material	Metal
International Protection (IP) code	IP52
Headphone outputs	1
Audio formats supported	AAC, MS-ADPCM, PCM
Cabling technology	10/100Base-T(X)
Supported network protocols	IPv4/v6, HTTP, HTTPS*, QoS 3 DiffServ, FTP, SMTP, Bonjour, UPnP, SNMPv1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Compliance industry standards	802.3at
AC input voltage	100-240 V
Power source type	PoE
AC input frequency	50 Hz
Power consumption (typical)	30 W
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	20 - 80 %

Weight and Dimensions

Width	198 mm
Height	240 mm
Weight	2600 g
