AXIS Q6035 PTZ Dome Network Camera
Events
HTTP Server
•Receivesnotification messages
• Receives uploaded images
• Descriptive name
• URL (IP address or host name)
• User name and password
• Proxy settings
TCP S erver
•Receivesnotification messages • Descriptive name
• Network address (IP address or host name)
• Port number
For details on each settings, see the online help .
Event Types
An Event Type describes how and when the Axis product performs certain actions.
Example
If somebody passes in front of the camera and an event has been configured to detect and respond to motion, the Axis product can
recordandsaveimagestoanFTPserverandsendanotification email. Images can be sent as email attachments.
Set up a triggered event
The following example describes how to configure the Axis product to upload images when motion is detected.
1. Go to Events > Motion Detection and set up a motion detection window. See
Set up motion detection, on page 33
.
2. Go to Events > Event Types and click Add triggered.
3. Enter a descriptive name for the event, for example Motion detected.
4. Set the Priority — high, normal or low.
5. Set the Respond to Trigger para meters to define when the event is active, for example, after office hours.
6. Select Motion detection from the Triggered By list. Se lect the desired motion detection window and indicate if the event
should be triggered when motion starts or stops (or both).
7. Set the When Triggered parameters, that is, define what the product should do when m otion is detected. To upload images,
select Save stream and enter the required information. S ee
Save stream
.
8. Click OK to save the event.
31
