AXIS Q6035 PTZ Dome Network Camera
Events
Note
• U p to 10 event types can be configured, and up to 3 of these can be configured to upload images.
• Filenamescanbeformattedaccordingtospecific requirements. See
File Naming & Date/Time Formats in the online help.
Set up a scheduled event
A scheduled event can be activated at preset times, in a repeating pattern on selected weekdays.
The following example describes how to configure the Axis product to upload im ages from pre-programmed time periods.
1. Go to Events > Event Types and click Add scheduled.
2. Enter a descriptive name for the event, for example Scheduled email upload.
3. Set the Priority — high, normal or low.
4. Set the Activation Time parameters (24h clock) for the event. For examp le, select Recurrence pattern and let the event
start on Sundays at 13.00 with a duration of 12 ho urs.
5. Set the When Activated parameters, that is, define what the product should do when the event is activated. To upload
images, select Save stream and enter the required information. See
Save stream .
6. Click OK to save the event.
Save stream
To upload images to an FTP or HTTP server, save the video stream to the SD card or send images by email, check the Save stream box.
Pre-trigger and post-trigger buffers are useful when checking to see what happened immediately before and afte r a tri gger. All
uploaded images are JPEG images.
Image frequency - Set the image frequency to a desired frame rate. The frame rate will be the best possible, but might not be as
high as sp ecified, especially if uploading via a slow connection.
Include pre-trigger buffer - Ima ges stored internally in the product from the time immediately preceding the trigger. Check the box
to enable the pre-trigger buffer a nd specify the buffer length in sec
onds, minutes or hours.
Include post-trigger buffer - Images stored i
nternally in the product from the time immediately after the trigger. Check the box to
enable the post-trigger buffer and specify the buffer length in seconds, minutes or hours.
Note
• Pre-trigger and post-trigger buffers will be lost if the connection to the event server fails.
• The maximum length of the pre-/post-trigger buffer depends on the video image size a nd selected frame rate.
• If the pre- or post-buffer is too large fo r the product’s internal memory, the frame rate is reduced and individual images
may be missing. If this oc
curs, an entry is created in the product’s log file.
Continue image upload (unbuffered) - Upload video images for a fixed length of time or for as long a s the trigge r is active.
Select type - Upload images to an FTP or HTTP server, send images by email or save the video stream to the SD card.
Create folder - Images uploaded to FTP and HTTP servers can be save d to designated folders. Folders can, for example, be named
using the current date and time, see
File Naming & Date/Time Formats in the online help.
Base file name - Used to name all upload ed images. Add a suffixoruseyourownfile format to give the images unique names, see
File Naming & Date/Time Formats intheonlinehelp.
Use s tream profile - Select the stream profile to upload, send as email or save to the SD card. When saving to the SD card, the video
format must first be selected. For information on stream profiles, see
Stream Pro files, on page 16 .
