Page #161 background image
A-2
Azbil CorporationNo. SS2-AVP300-0100
4
Item Specification
Performance Accuracy For 8 mA≤input signal span < 16 mA: ±1%F.S. (±2.5% with user-defined flow characteristics)
For 4 mA≤input signal span < 8 mA: ±1.5%F.S. (Refer to Table 1. Because accuracy varies depending
on the combination of actuator size and travel.)
Travel transmission
accuracy*
±1%F.S. (±2.5% with user-defined flow characteristics)
Stroke coverage 14.3 to 100 mm Stroke (Feedback Lever Angle ±4° to ±20°)
Enclosure classification JIS C0920 watertight, NEMA type 4X, IP66
Approvals TIIS Flameproof Ex d IIC T6 X
KOSHA Flameproof Ex d IIC T6
Flameproof cable gland must be Ex d IIC approved.
FM Explosionproof Explosionproof: Class I, Division 1, Group A, B, C, D
Dust-ignition: Class II, Division 1, Group E, F, G
Suitable: Class III, Division 1
Flameproof: Class I, Zone 1, AEx d IIC T6 at T
amb
<80°C
NEMA Type 4X
Installation should comply with NEC.
FM Intrinsically safe Intrinsically safe: Class I, II, III, Division 1, Group A, B, C, D, E, F, G, T4
Intrinsically safe: Class I, Zone 0, AEx ia IIC T4
Nonincendive: Class I, Division 2, Group A, B, C, D, T5
Suitable: Class II, III, Division 2, Groups F, G, T4
NEMA Type 4X, IP66
The barriers should be FM recognized types and comply with the following
conditions as follows:
Input signal line:
12.02≤V
max
≤30 V, I
max
=100 mA, P
max
=1 W, Ci=0 μF, Li=0.22 mH
For travel transmission line:
V
max
=30 V, I
max
=100 mA, P
max
=1 W, Ci=0.07 μF, Li=0.22 mH
Installation should comply with NEC.
ATEX Flameproof II 2 G Ex db II C T6 Gb −40°C≤T
amb
≤+75°C
IEC IP66
Flameproof cable gland must be Ex db IIC approved.
Note: IP66 waterproof and dust-proof performance can be assured by installing
an appropriate cable gland.
ATEX Intrinsically
safe
II 1 G Ex ia IIC T4
II 1 D Ex iaD 20 IP66 T135°C
IEC IP66
The barriers should be ATEX certified types and comply with the following
condition as follows:
Input circuit (terminals ±IIN)
Ui=30 V, Ii=100 mA, Pi=1 W, Ci=1 nF, Li=0.2mH
Output circuit (terminals ±IOUT)
Ui=30 V, Ii=100 mA, Pi=1 W, Ci=3 nF, Li=0.2mH
NEPSI Flameproof EX d IIC T6 Gb, Ex tD A20 IP66 T85 °C
Flameproof cable gland must be NEPSI Ex d IIC approved.
NEPSI Intrinsically
safe
Ex ia IIC T4-T6
The barriers should be NEPSI certified types and comply with the following
condition as follows:
Input circuit (terminals ±IIN):
Ui=30 V, Ii=95 mA, Pi=0.66 W, Ci=0μF, Li=0.2 mH
Output circuit (terminals ±IOUT):
Ui=30 V, Ii=95 mA, Pi=0.66 W, Ci=0μF, Li=0.2 mH
Combination of
NEPSI Flameproof
and Intrinsically safe
When used as NEPSI Flameproof, it complies NEPSI Flameproof approval
as above.
When used as NEPSI Intrinsically safe, it complies NEPSI Intrinsically safe
approval as above.
IECEx Flameproof Ex db IIC T6 Gb
IEC IP66
Flameproof cable gland must be Ex d IIC approved.
Note: IP66 waterproof and dust-proof performance can be assured by installing
an appropriate cable gland.
