Azbil AVP201 User Manual

Appendix A: Specifications
A-3
No. SS2-AVP300-0100Azbil Corporation
5
Item Specification
Approvals INMETRO
Flameproof
Ex db IIC T6 Gb
Flameproof cable gland must be Ex db IIC approved.
Note: IP66 waterproof and dust-proof performance can be assured by installing
an appropriate cable gland.
EAC Flameproof 1 Ex d IIC T6 X
IEC IP66
Flameproof cable gland must be Ex d IIC approved.
Note: IP66 waterproof and dust-proof performance can be assured by installing
an appropriate cable gland.
EAC Intrinsically safe 0 Ex ia IIC T4 X
IEC IP66
Note: IP66 waterproof and dust-proof performance can be assured by installing
an appropriate cable gland.
CNS Flameproof Ex d IIC T6 Gb X
IEC IP66
Flameproof cable gland must be Ex d IIC approved.
Note: IP66 waterproof and dust-proof performance can be assured by installing
an appropriate cable gland.
CE Marking EN61326-1:2013 (EMC), EN50581:2012 (RoHS)
Configuration tools Field Communication Software CommStaff Model CFS100
* This applies only to positioners with travel transmission (model AVP301). In this case, a power supply circuit for travel transmission is required.
Conditions of supply air (JIS C1805-1 (2001))
Item Specification
Particles Maximum diameter 3 μmm
Oil mist Less than 1 ppm at mass
Humidity of the air supply The dew point should be at least 10°C lower than the temperature of this device.
To meet the above specifications for instrument air, install the air purification devices listed below properly in the specified installation location.
Examples of air purification devices
Installation Air purification device SMC corporation CKD corporation
Compressor outlet or main line Line filter AFF series AF series
Mist separator AM series
Terminal device Air combination AW30 M3000S type
