A-8
Item Specification
Weight Body:
• For single acting actuator
Without Pressure regulator with filter: 3.3 kg
With Pressure regulator with filter: 4.0 kg
• For double acting actuator:Without Pressure regulator with filter: 3.6 kg
With Pressure regulator with filter: 4.3 kg
Valve travel detector: 1.0 kg
Cable: 0.2 kg/m
Outer diameter: 9.8 mm
Sheath material: PDC (PVC)
Performance Accuracy ±1%F.S. (±2.5% with custom output characteristics)
Depending on cable length, the accuracy varies as follows:
Cable length Accuracy
5 m ±1.2%F.S.
10 m ±1.7%F.S.
20 m ±2.7%F.S.
For 4 mA≤input signal span<8 mA, ±1.5%F.S.
Note: Depend on the air pipe diameter, or pipe length, the auto setup program will not properly
operate.
Travel
transmission
accuracy
±1%F.S. (±2.5% with output characteristics modification)
Only for travel transmission type (model AVP201)
Stroke coverage 14.3 to 100 mm Stroke (Feedback Lever Angle ±4° to ±20°)
Enclosure classification JIS C0920 watertight
Configuration tools Field Communication Software CommStaff Model CFS100
Approvals TIIS Flameproof Body: Ex d IIC T6 Approval No.TC17094
Valve travel detector: Ex d IIC T6 Approval No.TC20454
Conditions of supply air (JIS C1805-1 (2001))
Item Specification
Particles Maximum diameter 3 μmm
Oil mist Less than 1 ppm at mass
Humidity of the air supply The dew point should be at least 10°C lower than the temperature of this device.
To meet the above specifications for instrument air, install the air purification devices listed below properly in the
specified installation location.
Examples of air purification devices
Installation Air purification device SMC corporation CKD corporation
Compressor outlet or main line Line filter AFF series AF series
Mist separator AM series
Terminal device Air combination AW30 M3000S type
