Azbil AVP201 User Manual

A-12
Table 3. Mounting bracket for double acting actuator
(8)(9) Mounting bracket for pneumatic actuator Code
Pentair Valve and Control Japan AK09, AK12, AK15 KA
Pentair Valve and Control Japan AG06, AGN06 KG
Pentair Valve and Control Japan AG09, AGN09 KH
Pentair Valve and Control Japan AG13, AGN13 KJ
Pentair Valve and Control Japan AW13 KV
Pentair Valve and Control Japan AW17 KW
Pentair Valve and Control Japan AW20 KT
KITZ B series B-2 B2
KITZ B series B-3 B3
KITZ B series B-4 B4
KITZ B series B-5 B5
KITZ B series B-6 B6
Xomox (EL-O-MATIC) E25, 40, 65, 100, 200, 350 RA
Xomox (EL-O-MATIC) E600, 950, 1600, P2500, P4000 RB
Tomoe Valve Z series Z-06, 08, 11, 13 EA
Tomoe Valve T-matic 3I-1, 2, 3, 4 E3
T. V. VALVE AT4-80 V1
T. V. VALVE AT4-100 V2
T. V. VALVE AT4-120 V3
T. V. VALVE AT4-150 V4
T. V. VALVE AT4-180 V5
Note: In case of double acting actuator, a reversing relay unit required.
Table 4. Standard travel range and accuracy
Actuator Travel (mm) accuracy (%F.S.)
PSA1, 2 14.3, 20, 25 1
PSA3, 4 20, 38 1
HA1 6, 8, 10 3
14.3, 25 1
HA2 10 3
14.3, 25, 38 1
HA3 14.3 3
25, 38, 50 1
HA4 14.3 3
25, 38, 50, 75 1
VA 5 25, 37.5, 50, 75, 100 1
VA 6
PSA6, 7
14.3 3
25, 37.5, 50, 75, 100 1
HK1
PSK1
10 3
19 1
