Azbil HLS Series User Manual

11-11
Table 11-7. Parts list for expanded graphite
Part name Actuator model Material Part No. Qty.
Main packing
HA2
P6617CL 82573489- 001 3
Adapter packing P6720 82573475- 101 2
Carbon ring P6210C2FS 82573488- 001 2
Belleville spring SUS304 82571710- 101 6
O-ring (small) Viton 82592220- 897 1
O-ring (large) Viton 82592221- 897 1
Gland stud A193 GrB8CL2 82559311- 012 2
Gland nut SUS304 82592448- 163 2
Packing flange SCS13 82573456- 101 1
Packing follower SUS304 82573463- 201 1
Packing follower for
O-ring use
SUS304 82573464- 201 1
Spacer SUS304 82573476- 114 1
Main packing
HA3
(except 6B)
P6617CL 82573489- 002 3
Adapter packing P6720 82573475- 102 2
Carbon ring P6210C2FS 82573488- 002 2
Belleville spring SUS304 82573462- 107 6
O-ring (small) Viton 82592221-497 1
O-ring (large) Viton 82592222-297 1
Gland stud A193 GrB8CL2 82571706- 012 2
Gland nut SUS304 82592448- 173 2
Packing flange SCS13 82573457- 101 1
Packing follower SUS304 82573465- 201 1
Packing follower for
O-ring use
SUS304 82573466- 201 1
Spacer SUS304 82573476- 115 1
Stem connector S25C/S20C 82571732- 101 1
Main packing
HA3
(6B)
P6617CL 82573489- 003 3
Adapter packing P6720 82573475- 103 2
Carbon ring P6210C2FS 82573488- 003 2
Belleville spring SUS304 82559308- 102 6
O-ring (small) Viton 82592221- 797 1
O-ring (large) Viton 82592222- 897 1
Gland stud A193 GrB8CL2 82559311- 012 2
Gland nut SUS304 82592448- 163 2
Packing flange SCS13 82573458- 101 1
Packing follower SUS304 82573467- 201 1
Packing follower for
O-ring use
SUS304 82573468- 201 1
Spacer SUS304 82573476- 116 1
