Part name Actuator model Material Part No. Qty.
Main packing
HA4
P6617CL 82573489- 004 3
Adapter packing P6720 82573475- 104 2
Carbon ring P6210C2FS 82573488- 004 2
Belleville spring SUS304 82573462- 108 6
O-ring (small) Viton 82592221- 997 1
O-ring (large) Viton 82592223- 397 1
Gland stud A193 GrB8CL2 82571707- 012 2
Gland nut SUS304 82592448- 023 2
Packing flange SCS13 82573459- 101 1
Packing follower SUS304 82573469- 201 1
Packing follower for
O-ring use
SUS304 82573470- 201 1
Spacer SUS304 82573476- 117 1
Main packing
PSA6R
DAP560
P6617CL 82573489- 009 3
Adapter packing P6720 82573475- 204 2
Carbon ring P6210C2FS 82573488- 010 2
Belleville spring SUS304 82573462- 109 6
O-ring (small) Viton 82592223- 397 1
O-ring (large) Viton 82592224- 197 1
Gland stud A193 GrB8CL2 82592006- 769 2
Gland nut SUS304 82592448- 033 2
Packing flange SCS13 82573460- 101 1
Packing follower SUS304 82573471- 201 1
Packing follower for
O-ring use
SUS304 82573472- 201 1
Spacer SUS304 82553331- 779 1
Main packing
DAP1000(X)
P6617CL 82573489- 010 3
Adapter packing P6720 82573475- 205 2
Carbon ring P6210C2FS 82573488- 011 2
Belleville spring SUS304 82573462- 110 6
O-ring (small) Viton 82592224- 497 1
O-ring (large) Viton 82592235- 697 1
Gland stud A193 GrB8CL2 82592008- 369 2
Gland nut SUS304 82592448- 043 2
Packing flange SCS13 82573461- 101 1
Packing follower SUS304 82573473- 201 1
Packing follower for
O-ring use
SUS304 82573474- 201 1
Spacer SUS304 82553331- 975 1
