6-6
Actuator model HA3
Part name Q'ty For Stroke 25mm For Stroke 38mm
Scale plate 1 80225032-464 82554022-103
Spring
20-98{0.2-0.1} 8 82521206-101 82521206-103
80-240{0.8-2.4} 8 82521206-102 82521209-101
Rod
unit
R (Reverse action) 1 82521431-202 82521431-203
D (Direct action) 1 82521428-102 82521428-103
Actuator model HA4
Part name Q'ty
For Stroke
25mm
For Stroke
38mm
For Stroke
50mm
For Stroke
75mm
Scale plate 1 80225032-464 82554022-103 82521424-102 80224425-103
Spring
20-98{0.2-0.1} 8 82521244-104 82521207-101 82521207-102 82521210-103
80-240{0.8-2.4} 8 82521244-106 82521210-101 82521210-102
82827929-101*
82827930-101*
Rod
unit
R (Reverse action) 1 82521429-102 82521429-103 82521429-104 82521431-303
D (Direct action) 1 82521431-302 82521431-303 82521431-303 82521429-105
* : The quantity of springs is 8 set, with 2 springs for each set, or total 16 springs.
