4-4
Chapter 4. BASIC OPERATION
(5) Press the [ ] key or [v] key to change the SP value.
>> The digit being changed blinks. You can move to the digit to be changed by
pressing the [<] key.
(6) When the target value is displayed, press the [ENT] key.
>> The SP value is fixed. At this point, the SP value and SP No. are updated.
Note
• Direct setup function
The control can be executed using the SP value currently being changed
(indicated by blinking display) when the "Direct setup function is enabled" is
selected at direct setup function switching C-2 1 in the function setup.
(The [ENT] key does not need to be pressed to fix the SP value. However, to
switch the display by pressing the [DISP] key, press the [ENT] key to fix the SP
value, and switch the display.)
This function is useful when changing the SP value frequently or little by little.
(The factory setting is set to "Direct setup function is enabled".)
For the function setup method, refer to;
Chapter 5. ADVANCED OPERATION
• As shown in the following table, up to 4 SP values can be switched according to
the ON/OFF state of the external switch inputs when the "3: Switching of SP No."
is assigned at the external switch input function assignments C- 10 and C- 1 1 in
the function setup.
(If the number of SPs is two, set either one of C- 10 or C- 1 1 to “3: Switching of
SP No.”.) However, in this case, the SP No. cannot be updated using the [
] key or
[v] key. Only the SP value can be updated.
External switch input state
SP to be selected
Input 1 (DI1) Input 2 (DI2)
OFF OFF
SP-0
ON OFF
SP- 1
OFF ON
SP-2
ON ON
SP-3
Handling Precautions
• If the [DISP] key is pressed while the settings are being changed (when a digit
is blinking), the SP No. and SP value will not be saved and will revert to the
previous values.
• When “1: Analog setting” is selected at the flowrate setup method selection
C-03 in the function setup, and the operation is carried out using the SP value
according to the analog setting voltage, the operation to change the SP value
and SP No. using the [
] key or [V] key cannot be accepted.
• If no key is pressed for 10 seconds or more after performing the operation
while the multi-setting flowrate is displayed on the previous page, the display
will automatically return to the instantaneous flowrate display.
