5-2
Chapter 5. ADVANCED OPERATION
5 - 1 Function Setup
Follow the procedure below to set the functions such as event output type and external switch input assignments:
(1) Press the [DISP] key to display the integrated flowrate value.
>> "L" lamp lights.
(2) Keep the [
] key pressed for 3 seconds or more.
>> "0.r G" is indicated on the upper display. (Parameter setup mode)
(3) Keep the [
] key pressed for 3 seconds or more.
>> The item No. C-0 1 is indicated on the upper display, and the function setup
mode is entered.
(4) Press the [
] key or [V] key to select the target setup item No., and then press
the [ENT] key.
>> The current setting value being indicated on the display blinks.
(5) Press the [
] key or [V] key to display the target setting value, and then press
the [ENT] key.
>> The setting value is stored.
If other items are required to set up, return to the step (4) and repeat the procedure.
Otherwise, proceed to the step (6).
(6) Press the [DISP] key.
>> The mode is returned to the instantaneous flowrate display.
Handling Precautions
• If any operation is not performed for one minute after entering the function
setup mode, the display automatically returns to the regular display
(instantaneous flowrate display).
• If the [DISP] key is pressed while the operation in step (5) is performed
(indicated by blinking display), the setting value remains at the previous value
without being updated.
