Azbil MPC0002 User Manual

4-3
Chapter 4. BASIC OPERATION
4 - 2 Setting the Flowrate

Procedure for changing flowrate in digital setting
z
Single SP setting mode (number of SPs = 1 according to function setup C-04)
Follow the procedure below to change the SP value (setting flowrate).
(1) Press the [DISP] key.
>> The instantaneous flowrate value and SP value are displayed.
(Same as the display at power supply ON)
(2) Press the [
] key or [v] key.
>> The digit currently being changed blinks. You can move to the digit to be
changed by pressing the [ ] key.
(3) When the target value is displayed, press the [ENT] key.
>> The SP value is fixed. At this point, the SP value is updated.
Note
• Direct setup function
The control can be executed using the SP value currently being changed
(indicated by blinking display) when the "Direct setup function is enabled" is
selected at direct setup function switching C-2 1 in the function setup.
(The [ENT] key does not need to be pressed to fix the SP value. However, to
switch the display by pressing the [DISP] key, press the [ENT] key to fix the SP
value, and switch the display.)
This function is useful when changing the SP value little by little.
(The factory setting is set to "Direct setup function is enabled".)
For the function setup method, refer to;
Chapter 5. ADVANCED OPERATION.
z
Multi-SP setting mode (number of SPs = 2 to 4 according to function setup C-04)
Up to four SP values (setting flowrate values) can be switched by key operation and
by external switch inputs.
Follow the procedure below to change the SP No. and SP value.
(1) Press the [DISP] key.
>> The instantaneous flowrate value and SP value are displayed.
(Same as the display at power supply ON)
(2) Keep the [DISP] key pressed for 1 second or more.
>> The SP No. currently being selected (setting flowrate No.: SP-0 to SP-3)
is indicated on the upper display, and the SP value is indicated on the lower
display.
(3) Press the [
] key or [v] key to change the SP No.
(4) When the target value is displayed, press the [ENT] key.
