Connecting AC power supply
1. Ground the BA instrument by connecting a suitable grounding cable
to the grounding screw.
2. Verify that the AC power supply meets the BA instrument input
requirements.
3. Connect the AC power supply to the AC plug with a ground contact (prong).
Connecting 12 V DC power supply (accessory required)
1. Ground the BA instrument by connecting a suitable grounding cable to
the grounding screw.
2. Connect the DC power supply to DC input plug with the b2-approved
12 V DC power supply lead (i. e. GB0120 in accessory material list).
Operation with battery supply
When the internal battery is charged, the BA instrument does not need to
be connected to a power supply.
The BA display screen displays the battery status. For example, when the
integrated battery is fully charged, “Battery 100%” is displayed at the bottom
of the display screen.
To charge the internal battery, see section “Charging Internal Battery”.
