4 - 24
Adjustment (Main Unit)
Left and right feed d
og position adjustment
1.
Perform "4 - 26 Front/back, left/right posit
ion of feed dog adjustment"
2.
Start test mode (r
efer to 4.4 "Test Mode" for test mode st
artup methods).
3.
After pressing
and selecting
, press
, and
select "FEED DOG POSITION."
4.
Press
, and set the left-right feed dog position to center.
5.
Turn off the power, and remove the front cover.
6.
Adjust the left-right feed
dog position.
