2 - 58
Thread cutter module
Modules
4
Cutter holder assembly removal
1.
Remove the cutter holder assembly
1
.
2.
Remove the NT lower threa
d cutter
2
from the cutter holder asse
mbly
1
.
1
2
5
Thread hook assy. disassembly
1.
Remove the retaining ring E4,
and remove the polyester slider
1
,
polyester slider
2
and the thread hook assy
3
.
2.
Detach the
spacer
4
.
4
3
Retaining ring E4
1
2
6
Rubber removal
1.
Remove the retaining ring
E2, and remove the rubber
1
.
1
Retaining ring E2
