5 - 12
Failure Investigation for Electronic Parts
Problems with vertical needle movement and reverse stitching
Problems with vertical needle movement
and reverse stitching
Replace SS-VR F2 PCB assy.
Replace NP F2 PCB assy.
Is the BW switch assy. OFF?
When the upper shaft pulley is slowly
turned by hand, does the voltage
between pins 2 & 1, pins 4 &1 and
pins 5 & 1 on the main NF3D PCB
assy. vary 0 – 5 V DC?
Are the resistance values for the
Stop/start switch, reverse switch,
raise needle switch and the thread
cut switch normal?
• Switch resistance values
Switch pressed …… 1 Ω or less
Switch released …… ∞
N
N
N
Adjust the assembly of the
BW switch assy.
Y
Y
Y
Replace main NF3D PCB assy.
To Next Page
